Home > Specifications

Type 2100-103ATA

Main Body Specification
Outer Layer ABS Resin
Outer Dimension 1.52(W) x 2.12(D) x 2.3(H) meters
Inner Dimension 1.07(W) x 1.73(D) x 1.82(H) meters
Door Size 0.4(W) x 1.38(H) meters
Weight Approx. 960 kg
Equipment Intercom/Emergency Decompression Valve
Flexible Oxygen Tube/Casters/Emergency Stop Button/Digital Display(Pressure/Temperature/RH /Elapsed Time)/Power Code/LAN Cable/TV Cable
Pressure 1.3ATA Maximum
Control Unit Specification
Outer Layer SPHC
Dimension 0.5(W) x 0.54(D) x *1.24(H) meters
* The indicating lamp is inclusive.
Electricity AC100V 50/60Hz
Power Consumption 14A(1400W) Maximum
Weight Approx. 90kg
Equipment Compressor/Oxygen Concentrator/Interphone/
Indicating lamp
Function
Operation:
Touch-screen
Pressure: Selective among 1.1/1.2/1.3ATA
Timer: Selective among 30/40/50/60/90/120
Minutes




Type1800-1.3ATA

Main Body Specification
Outer Layer ABS Resin
Outer Dimension 1.05(W) x 1.84(D) x 1.92(H) meters
Inner Dimension 0.70(W) x 1.33(D) x 1.525(H) meters
Door Size 0.41(W) x 1.31(H) meters
Weight Approx. 690 kg
Equipment Interphone/Emergency Decompression Valve
Flexible Oxygen Tube/Casters/Emergency Stop Button/Digital Display(Pressure/Temperature/RH /Elapsed Time)/Power Code/LAN Cable/TV Cable
Pressure 1.3ATA Maximum
Control Unit Specification
Outer Layer SPHC
Dimension 0.5(W) x 0.54(D) x *1.24(H) meters
* The indicating lamp is inclusive
Electricity AC100V 50/60Hz
Power Consumption 14A(1400W) Maximum
Weight Approx. 90kg
Equipment Compressor/Oxygen Concentrator/Interphone/
Indicating lamp
Function
Operation:
Touch-screen
Pressure: Selective among 1.1/1.2/1.3ATA
Timer: Selective among 30/40/50/60/90/120 Minutes
